Drum brake for ISUZU D-Max I Platform / Chassis (TFR, TFS) 3.0 D 4x4 163 HP
change
Select your vehicle
Here you can find 76 quality car parts, such as Drum brake for your ISUZU D-Max I Platform / Chassis (TFR, TFS) 3.0 D 4x4 4JJ1-TC 120 kW from 01.2007
Article No.: SKBDM-0800085
More
- Fitting Position: Rear Axle
- Drum diameter [mm]: 295
- Outer brake drum diameter [mm]: 339,5
- Inner brake drum height [mm]: 60,5
- Number of Holes: 6
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 80,4
- max. brake drum reboring dimension [mm]: 296,5
- Fitted Diameter [mm]: 101
- Bore Diameter [mm]: 12,6
- Condition: new
Read the product details
Article No.: BF569
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 340
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 61
- Number of Holes: 6
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 208
- Centering Diameter [mm]: 101
- Condition: new
Read the product details
Article No.: 3432-S
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 340
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 62
- Rim Hole Number: 6
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 80
- Weight [kg]: 8,59
- Wheel Hub Diameter [mm]: 101
- Condition: new
Read the product details
Article No.: ADZ94703
More
- Fitting Position: Rear Axle
- Diameter [mm]: 339
- Rim Hole Number: 6
- Bolt Hole Circle Ø [mm]: 140
- max. brake drum reboring dimension [mm]: 296,5
- Weight [kg]: 8,3
- Centering Diameter [mm]: 101
- Thickness [mm]: 81
- Width [mm]: 61
- Number of mounting bores: 1
- Inner Diameter [mm]: 295
- for OE number: 8-98030-385-0
- Condition: new
Read the product details
Article No.: BD-3853
More
- Construction Year to: 12/2010
- Fitting Position: Rear Axle
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 60,5
- Number of Holes: 6
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 80,5
- Centering Diameter [mm]: 101,1
- Brake Type: Drum Brake
- Condition: new
Read the product details
Article No.: 14.D630.10
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 295,1
- Inner brake drum height [mm]: 60,5
- Number of Holes: 6
- Total brake drum height [mm]: 80,4
- max. brake drum reboring dimension [mm]: 296,5
- Fitted Diameter [mm]: 101
- Condition: new
Read the product details
Article No.: 7D0760
More
- Fitting Position: Rear Axle
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 60,5
- Rim Hole Number: 6
- Total brake drum height [mm]: 80,5
- max. brake drum reboring dimension [mm]: 296,5
- for article number: 7D0760
- Centering Diameter [mm]: 101
- Number of mounting bores: 1
- Condition: new
Read the product details
Sample photo
Article No.: 19-4921
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 339
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 73
- Number of Holes: 6
- Total brake drum height [mm]: 80
- max. brake drum reboring dimension [mm]: 296,5
- Centering Diameter [mm]: 101
- Condition: new
Read the product details
Article No.: 94043300
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 340
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 61
- Hole Arrangement/Number: 06/07
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 81
- max. brake drum reboring dimension [mm]: 296,5
- Supplementary Article / Supplementary Info Info 2: without wheel hub, without wheel bearing, without wheel studs
- Weight [kg]: 8,4
- Centering Diameter [mm]: 101
- Wheel Bolt Bore Diameter [mm]: 12,7
- Packaging length [cm]: 36,3
- Packaging width [cm]: 35,9
- Packaging height [cm]: 10,1
- Condition: new
Read the product details
Article No.: 8DT 355 302-961
More
- Fitting Position: Rear Axle
- Outer brake drum diameter [mm]: 340
- Inner brake drum diameter [mm]: 295
- Inner brake drum height [mm]: 61
- Hole Arrangement/Number: 06/07
- Bolt Hole Circle Ø [mm]: 139,7
- Total brake drum height [mm]: 81
- max. brake drum reboring dimension [mm]: 296,5
- Supplementary Article / Supplementary Info Info 2: without wheel hub, without wheel bearing, without wheel studs
- Weight [kg]: 8,4
- Centering Diameter [mm]: 101
- Wheel Bolt Bore Diameter [mm]: 12,7
- Assy./disassy. by qualified personnel required!
- Condition: new
Read the product details
